The Snus Packing Machine is a fully automatic multi-lane stick-sachet packaging solution engineered for snus powder and fine granules, delivering stable dosing accuracy, consistent sealing quality, and high-output production in a compact footprint. Designed to handle a wide range of packaging formats and downstream packing needs, it supports sachet packing for later loading into cans, bottles, bags, or pouches, making it ideal for scalable nicotine pouch and snus manufacturing lines. With integrated functions covering forming, filling, sealing, cutting, counting, and date/batch coding, the machine helps manufacturers reduce manual intervention, improve hygienic handling, and maintain repeatable pack quality across long production runs.
Product Advantages
- Fully automatic, end-to-end packaging workflow: integrates film feeding, forming, metering, filling, sealing, slitting, cutting, counting, and hot-stamp coding to streamline production and reduce labor dependency.
- Multi-lane productivity for higher throughput: multi-lane architecture enables parallel filling and sealing, improving output while keeping each lane consistent in weight and appearance.
- Material versatility for snus powder and granules: optimized for fine powders and small granules, and configurable for dry or wet granule processing based on moisture levels and dosing method.
- Precision control with PLC + touchscreen HMI: intuitive parameter setting and recipe-style operation help ensure repeatability across shifts and products, supporting quick changeover and stable running.
- Low-noise, stable drive system: stepper/servo-driven motion reduces operating noise and improves control accuracy for smooth film transport and consistent seal alignment.
- Clean, reliable sealing and cutting: back-seal bag structure with inner/outer sealing options and a flat-cut (die cut) design provides neat edges, uniform pack presentation, and dependable closure integrity.
- Flexible configuration for different production goals: selectable film web widths, bag widths, and bag lengths allow the machine to match product positioning and consumption scenarios.
- Engineering support and customization: experienced R&D capability enables tailoring of lane layout, metering components, and process details to suit specific powder characteristics and line requirements.
Technical Specifications
| Item | Dry Granule 4-Lane Back Seal | Wet Granule 4-Lane Back Seal |
|---|---|---|
| Product Name | Snus Packing Machine | |
| Automatic Grade | Automatic | |
| Packaging Material / Supported Output | Cans, Bottles, Bags, Pouches (sachets suitable for secondary packing) | |
| Applicable Material | Dry granules / snus powder | Wet granules |
| Measuring Method | Horizontal screw metering (dry) | Rotary metering (wet) |
| Material Moisture Range | 3–10% | 25–40% |
| Packaging Weight | 0.4–0.6 g | 0.4–0.6 g |
| Speed | 30–45 cuts/min | 30–45 cuts/min |
| Bag Style | Back-seal bag; inner and outer sealing | |
| Film Web Width (select one) | 120 mm / 128 mm / 136 mm | |
| Bag Size | Width 13 mm / 14 mm / 15 mm (select one) × Length 20–50 mm | |
| Vertical Seal | 4 mm, no pattern | |
| Horizontal Seal | 4 mm, no pattern | |
| Bag Pulling Method | Heat sealing & bag pulling; servo bending drive; horizontal sealing with up/down bag clamping | |
| Cutting Style | Flat cut (die cut device) | |
| Air Supply | 0.6–0.8 MPa; 2.5–3 m³/min | |
| Power | 220V / 50Hz; 3.5 kW | |
Application Areas
- Snus powder stick sachet packaging and multi-lane sachet production
- Nicotine pouch and herbal snus pouch ingredient packing (fine powders and granules)
- Tea granules, freeze-dried coffee granules, grains, and similar free-flowing materials
- Facilities requiring automated sachet packing for subsequent loading into cans, bottles, bags, or pouches
- Packaging lines needing integrated counting and batch/date hot-stamping for traceability
