JW-AM10 10-Head Salad Weigher (50 PPM) — High-Accuracy Multi-Head Weighing Scale
The JW-AM10 is a 10-head multi-head weighing scale engineered for fast, stable, and accurate portioning of bulky, large-piece, and high-volume products such as salads, vegetables, and fruits. With a large 5000 ml hopper volume and a maximum weighing speed of up to 50 packs per minute (PPM), it supports efficient production while maintaining consistent target weights. A 7-inch touch-screen interface streamlines operation, recipe setup, and daily monitoring, making the JW-AM10 an ideal choice for fresh and ready-to-eat lines where gentle handling and repeatable accuracy are critical.
Product Advantages
Designed for large-volume products: The 5000 ml hopper capacity supports bulky items and mixed compositions (e.g., salad blends) without compromising feeding stability.
High accuracy with reliable throughput: Achieves weighing accuracy of ±5–10 g while reaching up to 50 PPM, helping reduce giveaway and improve output consistency.
Flexible feeding control for smoother flow: Each linear feeder amplitude can be adjusted in auto or manual mode to match product characteristics, improving flowability and weighing precision.
Selectable top distribution options: Supports rotary top cone and vibration top cone configurations to optimize product distribution and reduce bridging for different materials.
Hygienic, easy-care structure: IP65 waterproof and dustproof design helps simplify cleaning and maintenance—especially valuable for fresh produce and salad applications.
Operator-friendly interface: 7” touch screen control panel with multi-language capability (including Spanish, Korean, German, French, Arabic, and more) supports global teams and quick training.
Expandable functions: Optional dimple plate, timing hopper, printer, and rotary top cone allow the machine to be tailored to specific packaging line needs.
Technical Specifications
| Model | JW-AM10-1-1 |
| Max. Single Dump Capacity (g) | 100–3000 g |
| Weighing Accuracy | ±5–10 g |
| Max. Weighing Speed | 50 PPM |
| Hopper Volume | 5000 ml |
| Control Panel | 7” Touch Screen |
| Optional Configurations | Dimple Plate / Timing Hopper / Printer / Rotary Top Cone |
| Driving System | Step Rotor |
| Power Requirements | 220 V / 2000 W / 50–60 Hz / 12 A |
| Packing Dimensions (mm) | 2179 (L) × 1382 (W) × 1805 (H) |
| Gross Weight | 650 kg |
Product Application Areas
Fresh-cut and ready-to-eat foods: salad mixes, leafy greens, vegetable blends, fruit bowls, and mixed produce portions.
Fresh produce processing: large granule and chunky materials that require gentle feeding and consistent distribution.
Food packaging lines: pairing with vertical form-fill-seal (VFFS) machines, baggers, tray filling systems, and downstream labeling or printing where stable, repeatable weights improve overall line performance.
