Product Introduction
The Packmate SK250 is a customized, high-speed automatic snus pouch packaging machine engineered for single-lane pouch making and accurate dosing of snus granules or powder. Designed as an integrated snus dosing and packaging unit, it automates film feeding, forming, metering, filling, and heat sealing to deliver consistent portion packs with stable output. Built for demanding production environments, the machine features a stainless-steel structure, a PLC-based control architecture, and a 7-inch touch screen for intuitive operation, fast parameter setup, and efficient daily management. With a compact footprint and reliable sealing performance, it supports manufacturers seeking repeatable pouch quality, reduced product loss, and streamlined labor requirements.
Product Advantages
Precision dosing with minimized waste. The measuring cup backflow metering system delivers stable, repeatable fills in the 0.4–0.6 g range, helping maintain weight consistency across batches while reducing spillage and material loss.
High-efficiency throughput. The equipment is optimized for high-speed pouch production, reaching 30–45 bags/min per single column, with a 4-column configuration to increase total output while keeping pouch appearance consistent.
Reliable heat sealing for pouch integrity. Heat sealing provides tight closure and barrier performance to protect freshness and reduce contamination risk. The sealing form is left-and-right sealed with no back pattern, producing clean, market-ready pouches.
Industrial-grade hygienic construction. A stainless-steel body supports long service life, corrosion resistance, and easier cleaning—well suited for continuous operation in production facilities with strict hygiene expectations.
Flexible electrical compatibility. Dual voltage support (220V/380V) improves installation flexibility across different factory standards and regions.
Operator-friendly controls. PLC control with a 7-inch touch screen simplifies adjustment of speed, temperature, and dosing settings, enabling quicker changeovers and improved stability during long runs.
Compact layout, production-ready design. The 1200 × 800 × 1800 mm footprint helps integrate the machine into existing lines without excessive space requirements, while the 3 kW power system provides stable performance for continuous packaging tasks.
Technical Specifications
| Item | Specification |
|---|---|
| Product Name | Snus Packing Machine (Customized) |
| Model | Packmate SK250 |
| Control System | PLC |
| HMI (Touch Screen) | 7 inch |
| Filling Type | Measuring Cup Backflow Metering |
| Suitable Product | Snus granules / snus powder (as per sample) |
| Packaging Type | Pouch |
| Film Width | 120 mm |
| Package Weight Range | 0.4–0.6 g/bag |
| Packaging Speed | 30–45 bags/min (single column) × 4 columns |
| Sealing Type | Heat sealing |
| Sealing Form | No pattern on the back; left and right sealed |
| Sealing Width | Longitudinal: 4 mm; Transverse: 5 mm |
| Machine Material | Stainless steel |
| Power | 3 kW |
| Voltage | 220V / 380V |
| Dimensions (L×W×H) | 1200 × 800 × 1800 mm |
Application Fields
The Packmate SK250 is designed for snus manufacturers and contract packers requiring stable, high-speed pouch packaging for portioned products. It is suitable for production lines that handle snus particles, granules, or fine powder and need consistent metering, clean pouch forming, and dependable heat sealing. Typical use cases include high-output snus pouch production, standardized portion packs for retail distribution, and scalable packaging operations where repeatability, hygiene-focused construction, and efficient operator control are critical. The machine’s adaptable electrical configuration (220V/380V) and compact industrial design make it practical for both newly built facilities and upgrades to existing packaging workshops.
